330707-00-10-10-12-05 Bently Nevada 11mm Probe – 3300 XL Proximity Sensor

Bently Nevada 330707-00-10-10-12-05 11mm Probe Overview

Key Specifications

• Brand & Model: Bently Nevada 330707-00-10-10-12-05 (3300 XL 11 mm probe).
• Tip Material: PPS (Polyphenylene Sulfide).
• Case Material: Stainless steel for durability.
• Cable Type: 75 Ω triaxial FEP cable with excellent insulation.
• Temperature Range: -52°C to +177°C, suitable for harsh environments.
• Storage Shelf Life: 1 year when stored properly.

Mechanical & Electrical Details

• Bend Radius: 25.4 mm minimum for the cable.
• Thread Depth Compatibility: UNF 0.94 in, M16×1.5 24 mm, M14×1.5 21 mm.
• Probe Torque: Maximum 45 N·m, recommended 15 N·m.
• Connector Torque: Maximum 0.6 N·m, finger-tight recommended.
• DC Resistance (1m cable): 5.9 Ω ± 0.5 Ω.
• Insulation Resistance: ≥ 1 × 10⁹ MΩ at 100 V DC.
• Capacitance: Approximately 30 pF.
• Shock & Vibration: Withstands 5000 g shock, 10 g vibration (5–500 Hz).
• Response Time: Less than 0.1 ms for dynamic measurements.

Frequently Asked Questions (FAQ)

• Is this a new and original Bently Nevada probe?
  Yes, we supply only brand-new, original 330707-00-10-10-12-05 units with full factory specifications.
• What is the typical lead time for shipping?
  We process orders within 5 business days. We use FedEx, UPS, and DHL for fast delivery.
• Does this probe work with the 3300 XL system?
  Absolutely. The 330707-00-10-10-12-05 is part of the Bently Nevada 3300 XL series and ensures full system compatibility.
• What is the temperature range for this model?
  The probe operates reliably from -52°C to +177°C, making it suitable for demanding industrial environments.
• Can I return the product if needed?
  Yes, we support a 30-day return policy for unused items in original packaging.
• What is the resistance value for the 1m cable?
  The DC resistance measures 5.9 Ω ± 0.5 Ω for precise signal transmission.

For complete technical reference, download the official datasheet: 3300 XL 11 mm Proximity Transducer System Datasheet (PDF).
