330701-00-10-90-12-00 Bently Nevada 11 mm Probe In Stock

Bently Nevada 330701-00-10-90-12-00: 3300 XL 11 mm Proximity Probe

• Manufacturer: Bently Nevada (Made in U.S.A).
• Product model: 330701-00-10-90-12-00 belongs to the 3300 XL series.
• Probe type: 11 mm proximity probe without armor.
• Thread specification: 1/2-20 UNF thread, max engagement 0.750 inch.
• Unthreaded length option: 00 = 0 inch.
• Overall case length option: 10 = 1.0 inch.
• Total length option: 90 = 9.0 meters (29.5 feet).
• Important note: This 9.0 meter probe works with the 9 meter Proximitor Sensor.
• Connector type: Miniature coaxial ClickLoc connector with FluidLoc cable.
• Agency approval: Option 00 = not required for this unit.

Technical Specifications at a Glance

• Probe tip material: Polyphenylene sulfide (PPS) offers excellent durability.
• Probe case material: AISI 304 stainless steel (SST) resists corrosion.
• Cable specification: 75 Ω triaxial cable with FEP insulation.
• Available probe lengths: 1, 5, or 9 meters total length.
• Operating temperature range: -51°C to +177°C (-60°F to +351°F).
• Storage temperature: Same as operating range for consistency.
• Low temperature caution: Exposure below -34°C (30°F) may damage the pressure seal.
• Pressure capability: Probe seals differential pressure using a Viton O-ring.
• Shipping weight: 0.17 kg per probe.
• DC resistance (RPROBE): 7.2 ± 0.8 ohms for 5.0m length (center to outer conductor).
• Case thread alternative: M16x1.5 with max thread engagement of 24 mm.
• Maximum thread engagement (1/2-20): 0.750 inch.
• Maximum probe case torque: 45.2 N•m (400 in•lb).
• Recommended probe case torque: 15.2 N•m (133 in•lb).
• Connector-to-connector torque (max): 0.565 N•m (5 in•lb).
• Recommended connector torque: Finger tight only.
• Minimum bend radius: 25.4 mm (1.0 inch) with or without armor.
• Probe total length this model: 9.0 meters (29.5 feet).

Frequently Asked Questions (FAQ)

• Q: Is the 330701-00-10-90-12-00 probe brand new and original?
  A: Yes, we provide only brand new, original Bently Nevada probes with full authenticity.
• Q: What is the exact cable length of this model?
  A: This probe has a total length of 9.0 meters (29.5 feet) as per option 90.
• Q: Can I use this probe with a Proximitor Sensor of different length?
  A: No, 9.0 meter probes work exclusively with the 9.0 meter Proximitor Sensor.
• Q: What is the maximum operating temperature?
  A: The probe operates from -51°C up to +177°C (-60°F to +351°F).
• Q: Do you have stock for this model?
  A: Yes, we have 330701-00-10-90-12-00 in stock and ready to ship.
• Q: How long does delivery take?
  A: We dispatch within 5 days via DHL, FedEx, or UPS. Delivery time depends on your location.
• Q: Can I return the probe if it does not fit my application?
  A: Yes, we support 30 days return from the date you receive the item.
• Q: What is the probe case thread type?
  A: It uses 1/2-20 UNF thread, with max engagement 0.750 inch; also M16x1.5 compatible.
• Q: Is the probe pressure tested before shipping?
  A: Standard units are not pressure tested. Contact Bently Nevada for custom testing.
• Q: What material covers the probe tip?
  A: The probe tip uses Polyphenylene sulfide (PPS) for robust performance.
