330103-00-04-10-02-00 - Bently Nevada 8 mm Proximity Probe

Bently Nevada 3300 XL 8mm Proximity Probe for Precision Vibration Monitoring

Detailed Technical Specifications

• Brand & Series: Bently Nevada 3300 XL Series.
• Complete Model Number: 330103-00-04-10-02-00.
• Measurement Range: The probe has a linear 2mm (80 mils) measuring range.
• Electrical Output: It delivers a -1 to -17 Vdc voltage signal.
• Electrical Accuracy: Coil resistance is ±0.5 kΩ for consistent performance.
• Temperature Range: Operates from -52°C to +260°C for extreme environments.
• Model Suffix Meaning: 00 (0mm unthreaded), 04 (40mm case), 10 (1.0m cable), 02 (ClickLoc connector).

Installation Guide and System Compatibility

• Use a maximum of 305 meters of shielded cable for signal integrity.
• The probe installs with a standard M10x1 thread (15mm max engagement).
• For best results, set the target gap to 1.27mm to achieve a -9Vdc output.
• This probe is fully compatible with intrinsic safety barriers (Ref. Drawing 141092).
• Proper installation ensures maximum environmental tolerance and anti-interference.

Packaging, Shipping, and Support

• Package Includes: One proximity probe, connecting cable, and documentation.
• Product Condition: All items are brand new, original, and in factory packaging.
• Inventory Status: This 330103-00-04-10-02-00 model is available from stock.
• Shipping Service: We ship worldwide using FedEx, UPS, and DHL express services.
• Processing Time: We dispatch all orders within 5 business days of payment.

Primary Industrial Applications

• Continuous gas turbine shaft vibration monitoring in power generation plants.
• Position and vibration measurement on high-speed compressors and centrifugal pumps.
• Protection of large motors, fans, and gearboxes in heavy industrial settings.
• Essential for predictive maintenance programs to prevent unplanned downtime.

Frequently Asked Questions (FAQ)

• Q: What is the main difference in the model suffix (-02-00)?
  A: The -02 specifies the ClickLoc connector type. The -00 indicates standard certification for this 330103-00-04-10-02-00 unit.
• Q: Can this probe be used in hazardous areas?
  A: Yes, it carries ATEX/IECEx certification (AEx/Ex ia IIC T5-T1 Ga) and is suitable for Class I Div 2, Groups A-D.
• Q: What is the resolution and sensitivity of this sensor?
  A: The Bently Nevada 3300 XL probe offers high resolution across its 2mm range with excellent sensitivity for small vibration changes.
• Q: What is your return policy if the part is not suitable?
  A: We offer a 30-day return policy for items in new, unused condition with original packaging.
• Q: How do I ensure accurate readings during installation?
  A> Follow the recommended 1.27mm gap setting, use proper shielded cable, and ensure the mounting surface is clean and secure.

For detailed wiring diagrams, mechanical dimensions, and full performance curves, please download the official system datasheet.

Download the Complete 3300 XL 8mm Proximity Transducer System Datasheet (PDF)

Contact Information: For sales inquiries or technical support, please email us at sales@nex-auto.com or message on WhatsApp: +86 153 9242 9628.

Authorized Partner: NexAuto Technology Limited
