2711P-T10C4D9 PanelView Plus 1000 Touch Terminal Allen-Bradley

Allen‑Bradley 2711P‑T10C4D9 PanelView Plus 6 Compact Terminal

Core Technical Specifications

• Display & Touch: 10.4‑inch active‑matrix TFT with analog resistive touch; 1 million actuations at 10‑110 g force.
• Resolution & Color: 640 x 480 pixels, 18‑bit color depth; display area measures 211 x 158 mm (8.3 x 6.2 in.).
• Backlight: CCFL type with 50,000 hours minimum life at 25 °C; field‑replaceable for extended service.
• Memory: 512 MB non‑volatile Flash storage plus 512 MB RAM for runtime operations.
• Power Input: 18‑32 VDC (nominal 24 VDC); maximum consumption 160 VA.
• Communication Ports: Ethernet (EtherNet/IP), RS‑232 (DF1), and 1 USB host; supports SD cards (1GB / 2GB) for external storage.
• Real‑time Clock: battery‑backed with replaceable battery for time‑stamped events.
• Environmental: operates from 0 to 55 °C; storage from ‑25 to 70 °C; 5‑95% non‑condensing humidity.
• Enclosure: NEMA Type 12 or 13 rated for industrial environments.
• Dimensions & Weight: 248 x 329 x 55 mm (9.77 x 12.97 x 2.18 in.); weighs 2.6 kg (5.7 lbs).

Connectivity and Integration

• The integrated Ethernet port supports EtherNet/IP protocol for modern industrial networks.
• RS‑232 interface uses DF1 protocol for point‑to‑point communication with PLCs or PACs.
• One USB host port allows connection of keyboards, mice, or removable storage devices.
• Optional SD card slot accepts 1GB or 2GB cards for additional non‑volatile memory.
• Support for FTP, PDF viewer, and ActiveX controls simplifies data exchange and documentation access.

Installation and Mechanical Design

• The modular design separates display, logic, and optional communication modules for flexible configuration.
• Mount the terminal in NEMA Type 12 or 13 enclosures per your application needs.
• Rated for industrial environments with robust resistance to electrical noise and vibration.
• Use copper wire cables (e.g., 2711‑NC13) for standard RS‑232 connections.
• Shipping dimensions: 16 x 14 x 8 inches; shipping weight 8 lbs for secure transport.

Package Contents

• 2711P‑T10C4D9 operator terminal (display + logic module).
• Touchscreen calibration stylus and quick‑start guide.
• Mounting clips and gasket for panel installation.
• Power terminal block and grounding hardware.
• No additional software or memory card included.

Shipping & Logistics

• We ship all orders within 5 business days via FedEx, UPS, or DHL.
• All units are brand new, factory‑sealed, and in original packaging.
• Tracking information provided immediately after dispatch.
• International shipping available with full customs documentation.
• Stock is available for immediate order processing.

Frequently Asked Questions (FAQ)

• Is the 2711P‑T10C4D9 still in production?
  This model is End‑of‑Life, but we supply new old‑stock and surplus units with full function guarantee.
• What is the backlight lifespan?
  CCFL backlight lasts 50,000 hours minimum at 25°C; field replacement is possible.
• What communication protocols does it support?
  EtherNet/IP and DF1 natively; optional modules support DH+, RIO, and DH‑485.
• Does it support PDF viewing?
  Yes, the terminal includes a PDF file viewer for manuals and diagrams.
• What is the return policy?
  We accept returns within 30 days of delivery for a full refund (buyer pays return shipping).
• How do I transfer applications?
  Use the Ethernet port, USB drive, or SD card with FactoryTalk View Studio.
• Is the touchscreen replaceable?
  The touchscreen is integrated; the display module must be replaced if damaged.
