22D PowerFlex 40P Allen-Bradley | 22D-E6P6N104

Allen-Bradley 22D-E6P6N104 PowerFlex 40P Drive Overview

Technical Specifications

• Brand: Allen-Bradley
• Model: 22D-E6P6N104
• Series: PowerFlex 40P
• Input Voltage: 414-660V AC
• Input Current: 8.3 A
• Input Power: 8.1 kVA
• Efficiency: 97.5%
• Power Factor: 0.98
• Enclosure: IP20 Panel Mount
• Frame Size: B

Performance Characteristics

• Short circuit rating: 100,000 A for system protection
• Heat dissipation: 160 W under normal operating conditions
• Carrier frequency range: 2-16 kHz for noise reduction
• Speed regulation: ±0.05% for precise control
• Power loss ride-through: 100 ms for uninterrupted operation

Protection Features

• Class 10 electronic motor overload protection
• Hardware overcurrent trip limit: 200% of rated current
• MOV-based phase-to-phase and phase-to-ground protection
• DC bus overvoltage trip: 1005V DC
• DC bus undervoltage trip: 390V DC

Control & Input/Output Capabilities

• Control modes: Sensorless vector and V/Hz
• Digital inputs: 7 programmable channels
• Analog inputs: 2 configurable signals
• Analog output: 1 programmable channel
• Relay output: 1 Form C contact
• Programmable acceleration/deceleration ramps: 4 sets

Product Documentation

• Download complete manual: PowerFlex 4 and 40 AC Drives PDF

Frequently Asked Questions

What input voltage range does this drive support?

• The drive accepts 414-660V AC three-phase power input.

What control modes are available?

• You can use either sensorless vector or V/Hz control modes.

Is this unit brand new and in stock?

• Yes, we supply only brand new, original units from available stock.

What protection features are included?

• The drive has comprehensive protection including Class 10 overload and MOV-based phase protection.

How many digital inputs does the drive have?

• It provides 7 digital inputs for flexible control integration.

Where can I find the installation manual?

• Download the complete manual using the PDF link in the documentation section.

What is your shipping time?

• We process and ship all orders within five working days.

For technical support or purchasing information, please contact our sales team.

Contact: sales@nex-auto.com
