22D PowerFlex 40P Allen-Bradley | 22D-E4P2N104

Allen-Bradley PowerFlex 40P Adjustable Frequency Drive

Core Technical Specifications

• Product model: 22D-E4P2N104 from Allen-Bradley's PowerFlex 40P series
• Input power: 600 Volts AC three-phase with 48-63 Hz frequency range
• Output capacity: 4.2 Amps delivering 3 HP (2.2 kW) power
• Enclosure type: Panel mount open style with IP20 protection rating
• Compact Frame Size B design suitable for space-constrained installations

Advanced Protection Features

• Removable Metal Oxide Varistor provides surge and ground fault protection
• Integrated DC brake transistor enables dynamic braking functionality
• Comprehensive overload protection: 150% for 1 minute, 200% for 3 seconds
• Bus overvoltage trip at 1005V DC and undervoltage protection at 487V DC
• 300% instantaneous current fault limit safeguards motor operations

Control & Performance Capabilities

• Dual control modes: Sensorless Vector and Volt/Hz motor control
• Sinusoidal PWM output with 2 to 16 kHz carrier frequency range
• Precise speed control: ±1% open loop, ±0.05% closed loop with encoder
• Multiple inputs: 5 programmable digital, 2 dedicated digital, plus analog inputs
• Double-channel incremental encoder support for enhanced positioning

Communication & Interface

• Human Interface Module with display and reset button for local control
• RS-485 communication port enables straightforward PC programming
• Easy parameter configuration and real-time monitoring capabilities
• Seamless integration with existing PLC and automation systems

Environmental Specifications

• Operating temperature range: 14°F to 122°F (-10°C to 50°C)
• Storage temperature capability: -40°F to 185°F (-40°C to 85°C)
• Maximum installation height: 1000 meters above sea level
• Suitable for various industrial environments and applications

Frequently Asked Questions

• Is this drive new and authentic?
  Yes, we provide only brand new genuine Allen-Bradley products.
• What input voltage does this model require?
  This drive operates on 600V AC three-phase power systems.
• Do you have current stock availability?
  Yes, we maintain ready stock for immediate shipment.
• What motor control methods are supported?
  Both Sensorless Vector and Volt/Hz control modes are available.
• How quickly can you ship my order?
  We process and ship all orders within five business days.
• Where can I find the technical manual?
  Download the PDF from the Product Documentation section above.
• What is your return policy?
  We offer 30-day returns for unused products in original packaging.

Product Documentation

• Complete technical manual: PowerFlex 4 and 40 AC Drives PDF

For technical support or purchasing information, contact our sales team.
