22D PowerFlex 40P Allen-Bradley | 22D-E1P7N104

High-Efficiency Motor Control Solution

Product Identification & Specifications

• Manufacturer: Allen-Bradley
• Product Series: PowerFlex 40P
• Model Number: 22D-E1P7N104
• Input Voltage: 600 Volts AC three-phase
• Frequency Range: 50–60 Hz (±10% tolerance)
• Phase Configuration: Three-Phase power system
• Output Current: 1.7 Amps maximum rating
• Power Output: 1 HP (0.75 kW) capacity
• Enclosure Type: Panel Mount, Open Type (IP20)
• EMC Filter: No CE filter included
• Frame Size: B compact design

Power Management & Protection

• Input Power: 2.1 KVA at 2.3 Amps
• Power Factor: 0.98 high efficiency rating
• Heat Dissipation: 50 Watts thermal loss
• Short Circuit Rating: 100,000 Amps withstand capability
• Overcurrent Protection: 200% of rated output trip
• Fault Current: 300% of rated current limit
• Power Loss Ride-Through: 100 milliseconds without stopping
• Overload Capacity: 150% for 1 minute, 200% for 3 seconds

Performance & Control Features

• Output Frequency: 0 to 500 Hz adjustable range
• Carrier Frequency: 2 to 16 kHz adjustable setting
• Output Voltage: 0 to motor rated voltage
• Speed Accuracy: ±1% with slip compensation
• Control Inputs: Digital and analog, ±0.05%–0.5% accuracy
• System Efficiency: 97.5% energy conversion
• Ramp Times: 0 to 600 seconds acceleration/deceleration
• Time Resolution: 0.1 second programming steps

Application Advantages

• Energy Savings: High efficiency reduces operating costs
• Precision Control: Accurate speed and torque regulation
• System Protection: Comprehensive fault and overload safeguarding
• Power Reliability: Ride-through capability for brief outages
• Thermal Management: Low heat loss extends component life
• Flexible Programming: Wide range of adjustable parameters
• Industrial Durability: Robust construction for harsh environments

Shipping & Customer Support

• Product Condition: New, factory-original equipment
• Inventory Availability: Stock maintained for quick shipment
• Processing Timeline: 5 business day shipping guarantee
• Delivery Options: DHL, FedEx, and UPS services available
• Technical Assistance: Professional application support
• Return Policy: 30-day satisfaction guarantee

Technical Support Questions

What is the efficiency rating of this drive?

• This model achieves 97.5% efficiency in power conversion

What short circuit protection does it offer?

• It withstands 100,000 Amps short circuit current

What is the maximum output frequency?

• The drive provides 0 to 500 Hz output frequency range

How accurate is the speed control?

• Speed accuracy is ±1% with slip compensation

What carrier frequency options are available?

• Adjustable from 2 to 16 kHz for motor noise control

How quickly do you process orders?

• We ship all products within 5 business days

Download complete technical specifications: PowerFlex 40P Series Technical Manual

For immediate technical support and purchasing information:

Contact: sales@nex-auto.com
