22D PowerFlex 40P Allen-Bradley 22D-B8P0H204

PowerFlex 40P AC Drive: Advanced Motor Control Solution

Technical Specifications

• Brand: Allen-Bradley
• Model: 22D-B8P0H204
• Input Voltage: 208-240 VAC ±10%
• Output Current: 8A continuous, 12A peak
• Overload Capacity: 150% for 60 seconds
• Speed Range: 0.5-400 Hz
• Control Methods: V/Hz and sensorless vector
• Switching Frequency: 2 kHz (adjustable to 8 kHz)
• Signal Input: 4-20 mA analog
• Communication: RS-485 Modbus
• Operating Temperature: -10°C to 50°C
• Storage Temperature: -40°C to 70°C
• Humidity: 5-95% non-condensing
• Precision: ±0.5% speed control

Installation Guide

• Mount the 22D-B8P0H204 on a flat metal panel surface
• Maintain at least 10 cm clearance at the top and bottom
• Use M4 screws with proper 4 N·m torque specification
• Connect line input L1, L2, L3 and earth ground properly
• Keep control wiring separate from all power cables
• Use shielded cable for analog signal connections
• Enable ground fault protection in parameter settings

System Compatibility

• Works with PowerFlex DC brake resistors (22D-BRM series)
• Compatible with CompactLogix and ControlLogix PLC systems
• Can be paired with PowerFlex line reactors or filters
• Supports Allen-Bradley Safe Torque Off safety modules

Packaging & Shipping

• Package Includes: One 22D-B8P0H204 AC drive and user manual
• Shipping Options: Worldwide delivery via FedEx, UPS, and DHL
• Processing Time: We ship all orders within five business days
• Product Condition: 100% brand new in original factory packaging

Frequently Asked Questions

• What is the input voltage range?
  The drive accepts 208-240 VAC input with ±10% tolerance
• What communication protocols are supported?
  It features RS-485 Modbus communication for system integration
• What is the speed control precision?
  The unit provides ±0.5% speed control accuracy
• What is the operating temperature range?
  It operates reliably from -10°C to 50°C temperature range
• What is your return policy?
  We provide a 30-day return policy for customer satisfaction

Download technical documentation: PowerFlex 4 and 40 AC Drives PDF

For technical support and purchasing, contact: sales@nex-auto.com
