22D-B012H204 22D PowerFlex 40P Allen-Bradley

Allen-Bradley PowerFlex 40P 2.2 kW (3 Hp) AC Drive – 22D-B012H204

Key Features

• Power Rating: 2.2 kW / 3 Hp motor capacity
• Input Voltage: 480V AC, 3-Phase power supply
• Output Current: 12 Amps maximum drive output
• Enclosure Type: IP20, NEMA UL Open protection rating
• Control Methods: Sensorless Vector, V/Hz, PWM technology
• Communication: Integrated RS-485 (DSI) network interface
• Ambient Temperature: -10°C to 50°C (IP20) operating range
• Mounting: Zero Stacking Option for space savings

Extended Technical Specifications

• Input Frequency: 47–63 Hz operating range
• Speed Regulation: ±0.5% (Sensorless Vector mode)
• Carrier Frequency: Adjustable up to 16 kHz
• Efficiency: Over 95% energy conversion rate
• EMC Filtering: External filters for EN55011 Class A/B
• Thermal Management: Built-in cooling system
• Protection Rating: -10°C to 40°C for IP30 applications
• Control Interface: Keypad and remote operation capable

Installation Requirements

• Provide adequate clearance for proper ventilation
• Ensure correct grounding for electrical safety
• Follow local electrical codes and regulations
• Use appropriate external EMC filters when required
• Maintain ambient temperature within specified limits
• Implement proper wiring practices for noise immunity

Package Contents

• One PowerFlex 40P 22D-B012H204 AC drive unit
• Installation and user documentation
• Mounting hardware and accessories
• Basic configuration guide

Frequently Asked Questions

• What is the horsepower rating of this drive?
  This model rated for 2.2 kW / 3 Hp motor applications.
• What input voltage does this drive require?
  It operates on 480V AC, 3-Phase power systems.
• What communication protocols are supported?
  Features integrated RS-485 (DSI) communication interface.
• What is the operating temperature range?
  Operates from -10°C to 50°C with IP20 enclosure rating.
• What control methods does this drive offer?
  Supports Sensorless Vector, V/Hz, and PWM control methods.
• What is the maximum output current?
  Provides 12 Amps maximum output current capacity.

Download technical documentation: PowerFlex 4 and 40 AC Drives

Contact our technical sales team: sales@nex-auto.com
