2090-CSWM1DG-18VA13 Allen-Bradley | Motor Cable

Product Overview: Allen-Bradley 2090-CSWM1DG-18VA13 Single Motor Cable

Key Technical Specifications

• Brand: Allen-Bradley
• Model: 2090-CSWM1DG-18VA13
• Series: 2090-Series Single Motor Cables
• Cable Type: Power and feedback conductors only (no brake pair)
• Conductor Size: 18 AWG power wires
• Nominal Voltage: 1000V rated construction
• Operating Temperature Range: -20°C to 90°C (-4°F to 194°F)
• Storage Temperature Range: -20°C to 70°C (-4°F to 158°F)
• Connector Style: SpeedTec DIN single connector (M1)
• Drive-End Termination: Flying leads with longer lead lengths (DG style)
• Outer Sheath Color: Orange (DESINA compliant)
• Overall Shielding Coverage: ≥ 85% tinned copper braid with aluminum/polyester tape
• Maximum Conductor Temperature: 105°C
• Static Bend Radius: 7 times the cable diameter

Frequently Asked Questions

• What is the difference between 2090-CSWM1DG and 2090-CSBM1DG?
  The 2090-CSWM1DG-18VA13 carries power and feedback wires only. The CSBM1DG variant adds a brake conductor pair for motors with holding brakes.
• Which servo drives work with the 2090-CSWM1DG-18VA13?
  This cable pairs with Kinetix 5500 and Kinetix 5700 servo drives from Allen-Bradley.
• Does this cable come with a connector kit?
  No. The DG cable style uses flying leads at the drive end. You need the 2198-KITCON-DSL connector kit separately for termination.
• Can I use this cable for continuous-flex applications?
  No. The 2090-CSWM1DG-18VA13 is a standard non-flex cable. Choose an LF-series variant for continuous-flexing machinery.
• What is the maximum cable length available?
  The 2090-Series single motor cables come in 1-meter increments up to 50 meters for standard non-flex versions.
• Is this product in stock and ready to ship?
  Yes. We carry this cable in stock and dispatch within 5 days. We support 30-day returns.
• What payment and shipping options do you offer?
  We accept standard payment methods and ship via DHL, FedEx, or UPS.
