1734-IB4D Allen-Bradley POINT I/O 4-Channel Sinking Input Module

1734-IB4D Allen-Bradley POINT I/O 4-Channel Sinking Input Module with Diagnostics

Technical Specifications and Electrical Data

• Allen-Bradley designs the 1734-IB4D as a digital DC sinking input module featuring four input channels with individual status LEDs.
• Input voltage category operates at 24V DC nominal with an acceptable range from 10V DC to 28.8V DC.
• Maximum input current per channel measures 5 mA ensuring compatibility with standard industrial sensors.
• POINTBus current consumption draws 50 mA at 5V DC from the backplane for efficient power usage.
• Power dissipation reaches 1.0 Watt maximum at 28.8V DC with thermal dissipation of 1.9 BTU/hour.
• Maximum thermal dissipation at 28.8V DC measures 3.4 BTU/hour under full load conditions.
• Keyswitch position sets to 1 preventing mismating with other module types in the system.
• Dimensions measure 56 x 12 x 75.5 mm (2.2 x 0.47 x 2.97 in.) with a compact form factor for space-saving panels.
• Weight approximates 32.3 g (1.14 oz) contributing to lightweight assembly on DIN rails.
• Terminal base screw torque requires 0.8 N-m (7 lb-in) for secure field wiring connections.
• Operating temperature range spans -20 to 55 degrees Celsius (-4 to 131 degrees Fahrenheit).
• Enclosure carries an open-style rating requiring installation within a protected enclosure.
• Mounting orientation supports both horizontal and vertical DIN rail installations for flexibility.

Frequently Asked Questions (FAQ)

• Is the 1734-IB4D brand new and authentic?
  Yes, we supply only 1734-IB4D modules in brand new, original factory-sealed condition.
• Do you have the 1734-IB4D in stock for immediate shipment?
  We maintain inventory of the 1734-IB4D and ship most orders within five business days.
• Which shipping carriers do you use for this module?
  We ship using FedEx, UPS, and DHL depending on your location and preference.
• What is the return policy for this Allen-Bradley module?
  We accept returns within 30 days of delivery for unused and resalable items.
• What makes the 1734-IB4D different from the standard 1734-IB4?
  The 1734-IB4D includes enhanced diagnostic features for fault detection while the standard version does not.
• What communication networks support the 1734-IB4D?
  The module works with ControlNet, DeviceNet, EtherNet/IP, and other open networks via compatible adapters.
• Can the 1734-IB4D mount horizontally or vertically?
  Yes, the module supports both horizontal and vertical DIN rail mounting orientations.
• What is the operating temperature range for this module?
  The 1734-IB4D operates reliably from -20 to 55 degrees Celsius (-4 to 131 degrees Fahrenheit).
