150-F135NBR 100 HP 460V AC Drive | Allen-Bradley SMC-Flex

Allen-Bradley 150-F135NBR SMC-Flex Solid State Controller Overview

Technical Specifications and Performance Metrics

• Brand and Manufacturer: Allen-Bradley.
• Exact Model Number: 150-F135NBR from the SMC-Flex product line.
• Controller Rating: The device supports 135 continuous Amps. It handles 100 Hp loads effectively when supplied with 460V AC power.
• Input Voltage Range: It accepts 200-460V AC, 3-phase inputs. The circuitry handles both 50 Hz and 60 Hz line frequencies without modification.
• Control Voltage: The unit requires 24V AC/DC control power. This separate control circuit ensures safe and reliable operation of the logic components.
• Operating Temperature Range: The controller operates at -5 to 50 degrees Celsius (23 to 122 degrees Fahrenheit). You can store the unit at -20 to 75 degrees Celsius.

Multiple Motor Starting Algorithms

• The 150-F135NBR provides seven different motor starting algorithms. These algorithms reduce mechanical stress on both the motor and connected equipment during startup.
• Soft start with selectable kickstart gradually applies power to the motor. This method minimizes torque spikes and extends mechanical component life.
• Current limit starting with selectable kickstart controls the inrush current precisely. This protects the motor and the power distribution system from excessive demand.
• Dual Ramp start allows two distinct acceleration profiles for varying load conditions. Full Voltage start provides immediate across-the-line starting when necessary.
• Preset Slow Speed and Linear Speed Acceleration options exist for precise positioning. These modes may require Tach Feedback for optimal performance and accuracy.

Frequently Asked Questions (FAQ)

• Is the Allen-Bradley 150-F135NBR a new original product? Yes, we supply only 100% new original Allen-Bradley units. You receive the authentic SMC-Flex controller with full manufacturer tracing.
• Do you have the 150-F135NBR in stock for immediate shipment? Yes, we have stock available. We maintain inventory of this specific model to ensure quick fulfillment for your projects.
• How quickly can you ship this solid-state controller? We ship within 5 days. We process orders promptly to minimize downtime in your operations.
• What are the available shipping methods for this drive? We ship using common carriers like FedEx, UPS, and DHL. You can choose your preferred shipping method at checkout.
• What is your return policy for the 150-F135NBR? We support returns within 30 days. The item must remain in its original, unopened packaging to qualify.
• What are the physical dimensions of the 150-F135NBR? The device measures 443.7 mm (17.47 inches) in height, 196.4 mm (7.74 inches) in width, and 205.2 mm (8.08 inches) in depth.
• Can I use the braking options as an emergency stop? No, none of the braking options should serve as an emergency stop method. You must provide separate emergency stop devices per safety regulations.
• What is the operating temperature range for this controller? The 150-F135NBR operates reliably at -5 to 50 degrees Celsius. Storage temperature range is -20 to 75 degrees Celsius.
• Does this controller work with 230V AC input? Yes, the 150-F135NBR accepts 200-460V AC input. The 135A current rating determines actual capacity at different voltages.
