Bently Nevada 3300 XL 8mm Proximity Probe

Product Identification & Configuration

Technical Specifications & Performance

Construction Materials

• Probe Tip Material: Chemical-resistant PPS polymer
• Housing Material: AISI 303/304 stainless steel
• Thread Specification: M10x1 with 15mm maximum engagement
• Connector System: Secure ClickLoc connector

Environmental Specifications

Global Safety Certifications

• ATEX/IECEx Certification: Full compliance for hazardous areas
• Intrinsic Safety Rating: AEx/Ex ia IIC T5-T1 Ga
• Class I Division 2: Groups A-D approved
• Zone Certification: Zone 0 and Zone 2 compliant
• CSA Certification: Canadian Standards Association approved

Installation Guidelines

• Mount using M10x1 threads with proper torque application
• Maintain maximum 15mm thread engagement for secure mounting
• Set optimal gap at 1.27mm for -9Vdc calibration point
• Verify voltage output within -1 to -17 Vdc range during setup
• Ensure proper ClickLoc connector engagement for reliable connection

Shipping & Delivery Information

Frequently Asked Questions

What certifications does this probe carry?
The Bently Nevada 330103-00-12-10-01-05 has ATEX, IECEx, CSA, and Class I Div 2 certifications.

What is the optimal calibration point?
Set the gap to 1.27mm to achieve the recommended -9Vdc output voltage.

What temperature range can this probe handle?
It operates from -52°C to +177°C standard, with extended tip rating to +218°C.

Is this suitable for hazardous locations?
Yes, it carries multiple certifications for Zone 0, Zone 2, and Class I Div 2 areas.

How quickly can you ship this product?
We process and ship all orders within 5 business days using major carriers.

Are these genuine Bently Nevada products?
Yes, we supply only brand new, original Bently Nevada 330103-00-12-10-01-05 equipment.

Download Complete Technical Documentation:
For detailed specifications and performance data, download the datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
