Proximitor Sensor - 330780-50-05 | Bently Nevada

Tersedia (29 unit), siap untuk dikirim
  • Vendor:

    Bently Nevada

  • Tipe:

    Proximitor Sensor

  • Country of Origin:

    USA

  • Dimensions:

    9*7*3cm

  • Weight:

    255 g

  • Tag: Proximitor sensor

Bently Nevada 330780-50-05 Proximitor Sensor

Technical Specifications
Parameter Specification
Brand & Model Bently Nevada 330780-50-05
System Length 5-Meter Integrated Cable
Mounting Options Panel and DIN-Rail Compatible
Housing Dimensions 6.35cm × 6.12cm × 8.13cm
Operating Temperature -52°C to +100°C
Measurement Linearity ±0.25% Accuracy
Frequency Range 20kHz to 1GHz

Electrical Characteristics
Electrical Parameter Value
Input Voltage Range -17.5Vdc to -26Vdc
Maximum Current Draw 12mA
Output Impedance 50Ω ±1%
Signal Stability <2mV/V
Surge Protection 3-Second Rating

Construction & Materials

  • Housing Material: A380 Aluminum Construction
  • Environmental Protection: IP67 Ingress Rating
  • Connection System: SpringLoc Tool-Free Terminals
  • Connection Cycles: 500 Reliable Connections
  • Calibration Standard: AISI 4140 Steel Target

Certifications & Compliance

  • Class I Division 1 Hazardous Area Certified
  • ATEX Zone 2 Explosive Atmosphere Approval
  • IEC 60079-0:2017 Explosion-Proof Standards
  • EMC Directive 2014/30/EU Compliance
  • 100% Humidity Tolerance Capability

Environmental Durability

  • Extended Storage Temperature to +105°C
  • 2,000-Hour Salt Spray Testing Validation
  • Wide Operating Temperature Range
  • Robust Industrial Construction
  • Reliable Performance in Harsh Conditions

Installation Features

  • Dual Mounting Panel and DIN-Rail Options
  • Tool-Free SpringLoc Terminal Connections
  • Compact Dimensions for Space-Constrained Areas
  • Easy Integration with Existing Systems
  • Flexible 5-Meter Cable System

Frequently Asked Questions

  • What hazardous area certifications does it have? Class I Div 1 and ATEX Zone 2
  • What is the standard calibration material? AISI 4140 steel target
  • What environmental protection does it offer? IP67 rating and 100% humidity tolerance
  • What mounting options are available? Both panel and DIN-rail mounting

Download Complete Technical Specifications: 3300 XL 11 mm Proximity Transducer System Datasheet
