SED4D-06 Digital Terminal Board Yokogawa

Yokogawa SED4D-06 Digital Terminal Board: Reliable Signal Interface

Key Technical Specifications

• Brand & Model: The board comes from the reputable manufacturer Yokogawa, specifically model SED4D-06.
• Configuration & Channels: It offers flexible 16 channels x 2 for single or dual-redundant digital signal setup.
• Safety Certification: The product is designed to comply with SIL3 safety standards for functional safety.
• Electrical Ratings: It features a withstand voltage of 500 V AC for one minute.
• Insulation Performance: The board maintains a minimum insulation resistance of 100 MΩ at 500 V DC.
• Terminal Type: Connections are made using reliable M4 screw terminals.
• Suffix Code Details: Suffix code '0' indicates the board operates without a surge absorber. Code '6' confirms ISA Standard G3 conformity with no explosion protection.
• Compatible Cable: For optimal performance, use the designated AKB331 connection cable.
• Product Weight: The unit has a manageable weight of 1.5 kg for easy handling.

Installation & Environmental Notes

• Follow the manufacturer's guidelines for proper mounting and wiring.
• Ensure the operating environment aligns with the product's specifications.
• Use the correct AKB331 cable to guarantee signal integrity and connection reliability.
• The M4 screw terminals provide a secure and standard connection point for wires.
• Verify all electrical ratings match your application's requirements before installation.

Packaging & Shipping

• Each order includes one Yokogawa SED4D-06 Digital Terminal Board.
• We ship all items using reliable carriers like FedEx, UPS, or DHL.
• Your board arrives as a brand new, genuine Yokogawa product in its original packaging.
• We maintain stock for fast order processing and dispatch.

Frequently Asked Questions (FAQ)

• Q: Is the Yokogawa SED4D-06 board a genuine product?
  A: Yes, we supply only 100% brand new and original Yokogawa equipment.
• Q: Do you have this terminal board in stock for immediate purchase?
  A: Yes, we typically have the SED4D-06 in stock and ready for shipment.
• Q: How soon will my order ship after I place it?
  A: We process and ship most orders within 5 business days from confirmation.
• Q: Which shipping methods do you offer for international orders?
  A: We use major global couriers including DHL, FedEx, and UPS for reliable delivery.
• Q: What does the suffix code '6' mean for the SED4D-06?
  A: The suffix '6' specifies that this version meets ISA Standard G3 and does not include explosion protection.
• Q: Can I return the product if it doesn't fit my application?
  A: We offer a 30-day return policy for items in their original, unopened condition.
• Q: What is the significance of the SIL3 rating on this board?
  A: The SIL3 (Safety Integrity Level 3) certification indicates the board is suitable for use in high-demand safety instrumented systems.

For technical specifications, pricing, or to place an order, please contact us.
