FANUC A06B-6110-H015 Power Supply 17.5kW 63A

FANUC A06B-6110-H015 Power Supply Module: 17.5 kW High‑Current 3‑Phase Solution for CNC

Key Technical Specifications

• Brand & Series: FANUC A06B Series – engineered for high‑performance automation and CNC environments.
• Electrical Ratings: 200-240V AC input (3‑phase), 283-339V DC output, 63 Amps at 200V. Total output power reaches 17.5 kW to satisfy energy‑hungry machinery.
• Environmental Tolerance: Operating temperature 0 to 40°C, maximum vibration 5G, altitude up to 1000 meters above sea level. These ratings guarantee stable operation in typical factory conditions.
• Frequency & Efficiency: Accepts 50/60 Hz line frequency without adjustment. Its design minimizes energy loss while converting three‑phase AC to high‑voltage DC.
• Weight & Construction: Weighs 5.44 kg (12.00 lbs). Rugged chassis withstands shock and vibration up to 5G, ensuring long service life.

Installation and Mechanical Data

• Mounting: Panel mount inside a control cabinet. Ensure adequate airflow around the unit for cooling.
• Dimensions: Compact footprint fits standard industrial enclosures. Always follow FANUC's manual for clearance.
• Connections: Terminal block for 3‑phase input and DC output. Use properly rated cables for 63 Amps.
• Cooling: Built‑in fan provides forced air. Keep ambient temperature between 0 and 40°C.

Frequently Asked Questions (FAQ)

• Is this power supply brand new and original?
  Yes, every FANUC A06B-6110-H015 we offer is brand new and genuine FANUC product.
• What CNC applications does this model support?
  It supports FANUC and many other CNC systems requiring 283-339V DC bus. Typical uses include machining centers, lathes, and automation lines with higher power demands.
• How does the 63‑amp rating benefit my system?
  Higher current (63A vs. standard 49A) allows driving multiple axes or larger spindle motors without overloading the power supply.
• Can I use it at 50 Hz and 60 Hz equally?
  Absolutely. The unit operates at both 50 Hz and 60 Hz without modification.
• What is the maximum altitude for safe operation?
  FANUC rates it for up to 1000 meters above sea level. Above that, derating may be required.
• Do you have stock available now?
  Yes, we maintain ample stock of the A06B-6110-H015. Most orders ship within 5 days.
