DS200FGPAG1A Gate Pulse Amp Board GE LS2100 Specs

DS200FGPAG1A Gate Pulse Amplifier Board – General Electric LS2100 Series

Key Technical Specifications

• Brand & Model: General Electric DS200FGPAG1A (Gate Pulse Amplifier Board).
• Series / OEM: LS2100 series by GE Energy.
• Part Manual: GEI-100223.
• Test Points: 30 total – 9 for Gate A, 9 for Gate B, and 12 for cell status monitors.
• Twelve-Pulse Converter Supply Voltage: 2080 or 3300 VAC.
• Compatibility: Not backwards compatible with older systems.
• Gate Driver Circuits: Two independent driver circuits.
• Fiber-Optic Connectors: 15 total – 1 transmitter and 14 receivers.

Fiber-Optic Network & Signal Features

• The DS200FGPAG1A board provides one fiber optic transmitter and 14 receivers.
• Two receiving ports support duplex fiber optic networks.
• The remaining ports serve simplex fiber optic networks.
• Fiber optics avoid electrical interference, perfect for industrial environments.
• These cables work alongside 3-phase power cables or any other wires.
• Fiber optic links extend much farther than copper wire networks.
• Adding repeaters doubles the network length; you may add up to two repeaters.
• When designing cable routes, do not exceed the recommended bend radius.
• A tighter bend may degrade transmission or damage the cables.
• Adjust signal power based on cable length and other factors.

Frequently Asked Questions (FAQ)

• Q: Is the DS200FGPAG1A a genuine GE board?
  Yes, it is a brand new original General Electric board from the LS2100 series.
• Q: What is the twelve-pulse converter voltage range?
  The board accepts 2080 VAC or 3300 VAC for the twelve-pulse converter input.
• Q: Can I use this board with older GE drives?
  No, the DS200FGPAG1A is not backwards compatible with previous designs.
• Q: How many fiber optic receivers does the board have?
  It includes 14 fiber optic receivers and 1 transmitter, total 15 connectors.
• Q: What is the typical lead time?
  We ship within 5 days via DHL, FedEx, or UPS. Express options available.
• Q: Do you have stock available now?
  Yes, we have the DS200FGPAG1A in stock – ready for immediate dispatch.
• Q: What is the return policy?
  We offer 30 days to return the board if it remains unused and in original condition.
• Q: Does the board include a manual?
  Refer to manual GEI-100223 for detailed technical specifications.
