Proximity Probe - 330101-02-32-10-02-00 - Bently Nevada

Bently Nevada 330101-02-32-10-02-00 Proximity Probe

Product Configuration

• Brand: Bently Nevada
• Model: 330101-02-32-10-02-00 8mm industrial probe
• Shank Type: 0.2 inch unthreaded design
• Housing Length: 3.2 inches compact size
• Cable Length: 1.0 meter standard length
• Connector: ClickLoc connector system
• Certification: No certification required

Technical Specifications

• DC Resistance: 7.59Ω ±0.50 at 1.0 meter
• Cable Capacitance: 69.9 pF per meter
• Linear Measurement Range: Up to 2.0 millimeters
• Optimal Gap Setting: 1.27mm at -9V DC
• Temperature Range: -52°C to +177°C operation
• Maximum Wiring Distance: 305 meters field distance

Durability & Protection

• CableLock retention with 330N pull strength
• 8mm PPS tip encapsulation for long life
• Viton O-ring seals for pressure containment
• Excellent humidity resistance: <3% ASF shift at 93% RH
• FluidLoc upgrade available for oil resistance
• 323 grams per meter weight density

Frequently Asked Questions

What is the housing length of this model?
The 330101-02-32-10-02-00 features a compact 3.2-inch housing for space-constrained installations.

What temperature range can this probe handle?
It operates reliably in extreme temperatures from -52°C to +177°C for demanding environments.

Does this probe require special certifications?
No, this model requires no specific certifications, making it suitable for general industrial use.

Download Complete Technical Documentation:
Get the full datasheet for detailed specifications: 3300 XL 8 mm Proximity Transducer System Datasheet

For custom configurations and technical support:
Contact our team at sales@nex-auto.com
