330901-22-12-10-02-00 3300 NSv Sensor - Bently Nevada OEM

3300 NSv Proximity Probes – Compact Eddy Current Sensor for Tight Spaces

Key Technical Specifications

• Brand: Bently Nevada.
• Model Number: 330901-22-12-10-02-00 – 3300 NSv Proximity Probes series.
• Unthreaded Length Option: 2.2 inches (Option 22).
• Overall Case Length: 1.2 inches (Option 12) – short case design.
• Total Length Option: 1.0 meter (39 inches, Option 10).
• Connector and Cable Type: Miniature coaxial ClickLoc connector with standard cable (Option 02).
• Agency Approval: Not required (Option 00).
• Probe Case Material: AISI304 stainless steel (SST).
• Probe Tip Material: Polyphenylene sulfide (PPS).
• Cable Specification: 75Ω coaxial, FEP insulated. Available lengths: 0.5, 1, 5, or 7 meters.
• DC Resistance (RPROBE): 4.2 ± 0.5 ohms for 1.0 meter length.
• Maximum Recommended Torque: 5.1 N•m (45 in•lb). Maximum rated: 7.3 N•m (65 in•lb).
• Thread Engagement Limit: Max 0.375 inches for 1/4-28 threads.
• Operating Temperature: -52°C to +177°C (-62°F to +351°F).
• Storage Temperature: -52°C to +177°C (-62°F to +351°F).

Frequently Asked Questions (FAQ)

• Q: Is this probe brand new and original?
  A: Yes, we supply only 100% brand new, original Bently Nevada 3300 NSv Proximity Probes.
• Q: Do you have stock for model 330901-22-12-10-02-00?
  A: Yes, we maintain ample stock of this exact configuration with the short 1.2 inch case.
• Q: What is the total length including cable?
  A: Option 10 gives you 1.0 meter (39 inches) from probe tip to connector.
• Q: Why choose the 1.2 inch case length?
  A: The short case fits into very tight mounting spaces where standard 4.0 inch cases cannot go.
• Q: Can I use this probe below -34°C continuously?
  A: Prolonged exposure below -34°C may cause premature pressure seal failure. Stay within -52°C to +177°C but avoid sustained low extremes.
• Q: How soon will you ship?
  A: We ship within 5 days after order clears. Express options include DHL, FedEx, or UPS.
• Q: What is your return policy?
  A: We support 30-day returns for unused items in original packaging.
• Q: Is the probe pressure tested before shipment?
  A: Bently Nevada does not pressure test each probe prior to shipment, but the design uses a Viton O-ring for differential pressure sealing.
