Yaqqol masofani o‘lchash sensori Bently Nevada - 330103-00-08-10-02-00

?? Bently Nevada 3300 XL 8mm Yaqinlik Probu: Aniqlik va Ishonchlilik

Model 330103-00-08-10-02-00 sanoat darajasidagi tebranish monitoringini taqdim etadi ¡À0.50¦¸ qarshilik chidamliligi va 1.0-metrli kabel bilan. Og'ir mashinalar, turbinalar va aylanuvchi uskunalar uchun ideal.

?? Asosiy Texnik Ma'lumotlar

• Brend: Bently Nevada
• Oraliq: 0.25¨C2.3mm (10¨C90 mils), chiziqli chiqish -1V dan -17V DC gacha
• Harorat: Ishlash harorati -62¡ãF dan +425¡ãF gacha (-52¡ãC dan +218¡ãC gacha)
• Ip: M10x1 bilan 15mm maksimal kirish
• Og'irligi: 323 g/m (11.4 oz/ft) zanglamas po'lat korpus

?? O'rnatish va moslik

• Optimal Bo'shliq: Tebranish uchun -9V DC (1.27mm/50 mils) da sozlangan
• Kabel: 3-o'tkazgichli himoyalangan triad, maksimal 1,000ft (305m)
• Muhr: Viton? O-ring, namlikka sinovdan o'tgan 93% (IEC 68-2-3)

? Sertifikatlar va xavfsizlik

• AEx/Ex ia IIC T1-T5 (Zona 0)
• AEx/Ex nA/ec IIC T1-T5 (Zona 2)

?? Qadoqlash va kafolat

• O'z ichiga oladi: Proba, 1.0m kabel, ClickLoc ulagichi, hujjatlar
• Kafolat: 12 oylik cheklangan kafolat

?? Haqiqiy dunyo qo'llanmalari

• Gaz turbina tebranish monitoringi
• Qog'oz zavodi roliklarini tekislash tizimlari

?Bog'lanish sales@nex-auto.com yoki +86 153 9242 9628

PDF faylini bu yerdan yuklab oling:3300 XL 8 mm Yaqinlik Transduseri Tizimi Ma'lumotnomasi Ko'proq Bently Nevada zaxirada

330103-00-03-05-02-05	330103-00-05-05-01-05	330103-00-08-05-02-05
330103-00-09-05-02-00	330103-00-07-05-02-00	330103-03-10-15-01-00
330103-00-04-15-02-00	330103-00-05-50-02-00	330103-00-16-50-02-00
330103-06-10-50-02-00	330103-00-03-50-02-00	330103-00-04-50-02-00
