XBTGT1130 Schneider Magelis HMI Touch Panel

Schneider Electric Magelis XBTGT1130 3.8-Inch HMI Touch Panel

Technical Specifications

• Brand: Schneider Electric
• Model: XBTGT1130
• Series: Magelis
• Display Size: 3.8-inch TFT color touchscreen
• Resolution: 320 × 240 pixels (QVGA)
• Supply Voltage: 24 V DC
• Display Type: TFT color, touch-sensitive
• Manufacturer: Schneider Electric

Key Performance Details

• The touch panel offers a 320 × 240 pixel QVGA display for clear graphics.
• It runs on 24 V DC power for stable industrial use.
• The 3.8-inch TFT screen shows vivid colors and sharp text.
• Schneider Electric designs this Magelis unit for easy machine integration.
• The XBTGT1130 supports simple touch input for daily operations.

Installation Guide

• Mount the HMI panel into a prepared cutout on your control cabinet.
• Connect the 24 V DC power supply with correct polarity.
• Use the recommended Schneider Electric cables for communication.
• Secure the panel with the provided mounting clips.
• Power on the unit and verify the 320 × 240 display appears.
• Configure your project with the compatible Magelis software.

Package Contents

• 1 × Schneider Electric Magelis XBTGT1130 HMI panel
• 1 × Mounting clip set
• 1 × Power connector
• 1 × Quick start guide

Shipping and Support

• We ship via FedEx, UPS, and DHL for global delivery.
• All units are brand new and original.
• We keep this model in stock for fast dispatch.
• We send orders within 5 days after payment.
• We accept returns within 30 days.

FAQ

• Q: What is the display resolution of the XBTGT1130?
  A: The screen offers 320 × 240 pixels (QVGA).
• Q: What power supply does this Magelis panel need?
  A: It requires 24 V DC.
• Q: Is the XBTGT1130 touchscreen?
  A: Yes, it features a 3.8-inch TFT color touchscreen.
• Q: How many days for delivery?
  A: We ship within 5 days using DHL, FedEx, or UPS.
• Q: Can I return the product?
  A: Yes, we support 30-day returns.
• Q: Is the product new and original?
  A: Yes, every unit is brand new and original.
