Low Frequency Trendmaster Pro Accelerometer | 200155-07-05

Bently Nevada 200155-07-05 Industrial Vibration Monitor

Model Number Breakdown

• Base Model: 200155 series industrial accelerometer
• Suffix -07: Indicates mounting style with a 3/8-24 to 3/8" NPT adapter included
• Suffix -05: Confirms the unit is certified for hazardous areas

Key Product Features

• Made in the USA ensuring high manufacturing quality and reliability
• Wide operating temperature range from -40°C to +105°C
• Robust housing provides a strong seal against water and dust ingress
• Requires standard 5V DC power for operation

Technical Specifications

• Brand & Manufacturer: Bently Nevada
• Product Model: 200155-07-05
• Measurement Range: Up to 20g (196 m/s²) peak vibration
• Frequency Response: From 1.5 Hz to 10,000 Hz (10 kHz)
• Sensitivity: 10.2 mV per m/s² (approximately 100 mV/g)
• Weight: Approximately 2 ounces (58 grams)
• Dimensions: Compact size, roughly 11/16" x 1.8"
• Output Signal: Low-impedance voltage output compatible with most monitors

Straightforward Installation Guide

• Use the included 3/8" NPT adapter for mounting on compatible machinery
• Apply a tightening torque between 2 to 5 ft-lbs (2.7 to 6.8 N·m)
• Allow a 24-hour (1 day) stabilization period after installation
• This ensures accurate baseline readings and long-term sensor stability

Frequently Asked Questions (FAQ)

• Q: Do you have this specific model in stock?
  A: Yes, the 200155-07-05 is typically available from our ready stock.
• Q: What is your standard shipping timeline?
  A: Orders are processed and shipped within 5 business days.
• Q: Which courier services do you use?
  A: We ship worldwide via reliable carriers like DHL, FedEx, and UPS.
• Q: Is there a return option if the product is unsuitable?
  A: We offer a 30-day return policy for items in original, unused condition.
• Q: What power supply does this vibration sensor need?
  A: The 200155-07-05 operates on a standard 5V DC constant voltage supply.
• Q: What is the main advantage of the "-07" mounting option?
  A: The "-07" provides a 3/8" NPT threaded adapter, common for direct pipe mounting in industrial settings.

Access the full technical documentation for this sensor series, including detailed specifications and wiring diagrams. Download the Complete 200155 Series Accelerometer Datasheet PDF Here.
