140DAI75300 32-Channel 230V AC Input Module Schneider

Schneider Electric Modicon Quantum 140DAI75300 Discrete Input Module

Core Technical Specifications

• Brand & Model: This is an original Schneider Electric module from the Modicon Quantum series, model 140DAI75300.
• Input Channels & Voltage: The module provides 32 discrete input channels for 230 Volts AC signal acquisition.
• Signal Logic Levels: It recognizes a valid "ON" signal between 165-264V AC and an "OFF" signal between 0-40V AC at 57-63 Hz.
• Isolation & Protection: Inputs are organized into 4 isolated groups, each with 1780 Vrms isolation from others and the bus.
• Environmental Rating: Built for industrial environments, operating in 0 to 60 °C (32 to 140 °F) and up to 95% non-condensing humidity.
• Response Speed: Features fast response times: Off-to-On in 4.9-0.75 ms per line cycle and On-to-Off in 7.3-12.3 ms.

Installation & Wiring Guidelines

• The Modicon Quantum 140DAI75300 uses a standard module format for easy installation in any Quantum rack.
• Connect your 230V AC sensors and switches to the 32 dedicated input terminals.
• This module requires 2 input words for proper addressing in your PLC program.
• Ensure the connected AC power frequency is within the 47 to 63 Hz range for accurate operation.
• The module draws 250 mA from the backplane bus; please verify your rack's power budget.

Frequently Asked Questions (FAQ)

• Is the 140DAI75300 module brand new and authentic?
  Yes, we supply only 100% new, original Schneider Electric 140DAI75300 modules.
• What voltage does this input module accept?
  It is designed for standard industrial 230V AC input signals.
• How many devices can I connect to it?
  You can connect up to 32 individual devices to its input channels.
• Which programming software is compatible?
  It is fully compatible with Concept, Unity Pro, and ProWORX 32 software.
• What is the operating temperature?
  It operates reliably in a wide range from 0 to 60 °C (32 to 140 °F).
• What is the shipping and return policy?
  We ship within 5 days via major carriers. Please note this specific product has a manufacturer returnability status of "No".
