21000-34-10-20-018-04-02 Probe Housing Assembly Bently Nevada

Bently Nevada 21000 Proximity Probe Housing Assemblies – Technical Overview

Key Technical Parameters

• Brand: Bently Nevada
• Model: 21000-34-10-20-018-04-02
• Probe Option: 3300 XL 8 mm probe with connector protector
• Probe Cable Length: 1.0 m (39 inches)
• Standoff Adapter: 2.0 inches
• Probe Penetration: 1.8 inches
• Fitting Option: One 3/4-14 NPT plug only
• Mounting Thread Option: 3/4-14 NPT
• Maximum (C) + (D) with visible probe: 17.0 inches (43.18 cm)
• Maximum (C) + (D) Dimension: 32.9 inches (83.5 cm)
• Weight: 1.1 kg (2.4 lb) typical without fittings
• Material: Aluminum body with 304 stainless steel sleeve
• Enclosure Rating: CSA Type 4, explosion-proof for hazardous areas
• Standard Compliance: API 670 for externally mounted housings

Frequently Asked Questions (FAQ)

• Q: Is this 21000 unit brand new?
  A: Yes, it is a new and original unit in factory packing.
• Q: Does this housing work with intrinsically safe systems?
  A: Yes, you can order hazardous area approved probes for this housing.
• Q: What cable length does the 21000-34-10-20-018-04-02 include?
  A: It includes a 1.0 meter probe cable.
• Q: Is this assembly explosion-proof for CSA?
  A: Only CA versions with E:00, E:01, E:02, or E:04 options are CSA-rated.
• Q: How long is the standoff adapter?
  A: The standoff adapter measures 2.0 inches.
• Q: Do you have this model in stock?
  A: Yes, we have this model in stock and ready to ship.
