6ES7531-7KF00-0AB0 Siemens S7-1500 Analog Input Module

Technical Specifications of 6ES7531-7KF00-0AB0

• Brand: Siemens
• Model: 6ES7531-7KF00-0AB0
• Type: Analog input module AI 8xU/I/RTD/TC ST
• Channels: 8 analog inputs, 4 channels for RTD measurement
• Resolution: 16 bit with overrange
• Accuracy: 0.3% operational error limit for voltage, current, and resistance
• Common mode voltage: 10 V max
• Input ranges: ±10V, ±5V, ±2.5V, ±1V, 1-5V, 0-20mA, 4-20mA, ±20mA
• Thermocouple types: B, E, J, K, N, R, S, T
• RTD support: Pt100, Pt200, Pt500, Pt1000, Ni100, Ni1000, LG-Ni1000
• Resistance ranges: 0-150Ω, 0-300Ω, 0-600Ω, 0-6000Ω, PTC
• Integration time: Parameterizable (2.5/16.67/20/100 ms)
• Cable length: 800 m shielded for U/I, 200 m for RTD, 50 m for TC
• Supply voltage: 24 V DC (20.4 to 28.8 V)
• Power loss: 2.7 W typical
• Operating temperature: 0 °C to 60 °C horizontal installation
• Dimensions (WxHxD): 35 mm x 147 mm x 129 mm

Frequently Asked Questions (FAQ)

• Is the 6ES7531-7KF00-0AB0 brand new and original? Yes, we supply only brand new and original Siemens modules.
• Do you have this module in stock? Yes, we keep the 6ES7531-7KF00-0AB0 in stock for immediate orders.
• What is the typical delivery time? We ship within 5 business days after payment confirmation.
• Which carriers do you use? We ship via FedEx, UPS, or DHL – you choose at checkout.
• Can I return the module? Yes, we support returns within 30 days of delivery.
• What thermocouple types does this module support? It supports B, E, J, K, N, R, S, and T types.
• Does the module provide temperature compensation? Yes, it offers internal, external via RTD, or fixed 0°C reference compensation.
• What is the common mode voltage limit? The maximum common mode voltage between inputs and MANA is 10 V.
