330902-00-10-10-01-05 3300 NSv Probe | Bently Nevada

Bently Nevada 330902-00-10-10-01-05: 3300 NSv Proximity Probe Specifications & Technical Data

• Brand & Model: Bently Nevada 3300 NSv Proximity Probe | Product No. 330902-00-10-10-01-05. This model includes a miniature coaxial ClickLoc connector with a protective cap.
• Mechanical Configuration: 1/4-28 UNF probe case with 0.0-inch unthreaded length option. The overall case length option 10 equals 1.0 inch (25.4 mm). Total length option 10 provides a 1.0 meter (39 inches) FEP insulated coaxial cable.
• Materials: Probe case uses AISI304 stainless steel (SST). Probe tip material is polyphenylene sulfide (PPS), ensuring excellent chemical resistance. The cable features 75 ohm coaxial construction with fluoroethylene propylene (FEP) insulation.
• Electrical Characteristic: DC resistance from center conductor to outer conductor (RPROBE) equals 4.2 ± 0.5 ohms for the 1.0 meter probe length. This precise resistance ensures reliable signal integrity.
• Torque Specifications: Maximum rated torque for the 1/4-28 probe case reaches 7.3 N•m (65 in•lb). Recommended installation torque equals 5.1 N•m (45 in•lb). Maximum thread engagement length equals 0.375 inches.
• Temperature Ratings: Operating temperature ranges from -52°C to +177°C (-62°F to +351°F). Storage temperature matches the same range. Avoid exposing the probe below -34°C (-30°F) for long periods to protect the pressure seal.
• Agency & Safety Approvals: Option 05 indicates Multiple Approvals including EPL Ga, Gc, and Dc temperature classifications. For EPL Ga/Gc: T1 (-55°C to +232°C), T2 (-55°C to +177°C), T3 (-55°C to +120°C), T4 (-55°C to +80°C), T5 (-55°C to +40°C). For EPL Dc: T280°C max at Ta -55°C to +232°C, T225°C at -55°C to +177°C, T170°C at -55°C to +120°C, T130°C at -55°C to +80°C, T105°C at -55°C to +100°C, T90°C at -55°C to +40°C.
• Pressure & Seal: The 3300 NSv probe seals differential pressure between tip and case using a Viton O-ring. Bently Nevada does not pressure test each probe prior to shipment.
• Physical Weight: Probe weight falls between approximately 14 to 150 grams (0.5 to 5.3 ounces), suitable for light industrial mounting.

Frequently Asked Questions (FAQ)

• Q: What shipping methods do you use?
  A: We use FedEx, UPS, and DHL. The system automatically selects the most efficient courier for your region.
• Q: What is the return policy for this proximity probe?
  A: We offer 30-day returns from the delivery date. The probe must remain unused and in original packaging.
• Q: Can I use this probe in a high-pressure vessel?
  A: The 3300 NSv seals differential pressure between tip and case using a Viton O-ring. However, Bently Nevada does not pressure test each probe before shipment. Verify compatibility with your specific pressure level.
• Q: Does the probe resistance vary with temperature?
  A: The specified 4.2 ± 0.5 ohms DC resistance applies at room temperature. Expect minor resistance changes within the -52°C to +177°C operating range, but this does not affect typical proximity measurements.
• Q: What torque should I apply to the 1/4-28 threads?
  A: Always use the recommended torque of 5.1 N•m (45 in•lb). Exceeding the maximum 7.3 N•m may strip threads or damage the case.
• Q: Is the cable replaceable if damaged?
  A: The cable is integral to the 3300 NSv Proximity Probe. You cannot replace the cable separately. Order a new probe assembly if the cable sustains damage.
• Q: How long will delivery take after shipping?
  A: Once shipped via FedEx/UPS/DHL, expect delivery within 2 to 7 business days depending on customs and distance.
• Q: Does the probe tip resist oil and moisture?
  A: Yes, the Polyphenylene sulfide (PPS) tip resists most oils, solvents, and moisture commonly found in turbine and compressor environments.

For any technical or sales inquiries, please contact us: sales@nex-auto.com or +86 153 9242 9628 (WhatsApp). Our team supports your 3300 NSv installation needs.
