330104-00-12-10-01-00 Bently Nevada 3300 XL 8mm Probe

Bently Nevada 330104-00-12-10-01-00 3300 XL 8 mm Proximity Probe

Key Technical Specifications

• Brand: Bently Nevada. Model: 330104-00-12-10-01-00. Type: 3300 XL 8 mm Proximity Probe, Metric.
• Linear Range: 2 mm (80 mils). It starts at 0.25 mm (10 mils) from the target. It runs from 0.25 mm to 2.3 mm (10 to 90 mils).
• Recommended Gap Setting (Radial Vibration): -9 Vdc. This equals approximately 1.27 mm (50 mils).
• Probe Tip Material: Polyphenylene sulfide (PPS). Probe Case Material: AISI 303 or 304 stainless steel (SST).
• Probe Case Thread: M10x1. Maximum thread engagement length: 15 mm.
• Unthreaded Length Option (00): 0 mm. Overall Case Length Option (12): 120 mm.
• Total Length Option (10): 1.0 meter (3.3 feet). Connector Option (01): Miniature coaxial ClickLoc connector with protector, standard cable.
• Nominal DC Resistance (RPROBE): 7.59 ± 0.50 Ω for 1.0m length. This measures from center conductor to outer conductor.
• Operating & Storage Temperature (Standard Probe): -52°C to +177°C (-62°F to +350°F). Exposing the probe below -34˚C (-30˚F) may damage its pressure seal prematurely.
• Extended Temperature Range Probe: Tip works from -52°C to +218°C (-62°F to +425°F). Cable and connector work from -51°C to +260°C (-60°F to +500°F).
• Relative Humidity: Less than 3% change in Average Scale Factor (ASF) when tested at 93% humidity for up to 56 days per IEC 68-2-3.
• Agency Approval Option (00): Not required. However, the probe works with intrinsic safety barriers (per drawing 141092) or galvanic isolators for hazardous areas: Class I, Zone 0 (AEx/Ex ia IIC T5...T1 Ga) and Class I, II, III divisions.
• Non-incendive Option (nA, ec): Use with non-incendive circuit per drawing 140979 for Class I, Zone 2 (AEx/Ex nA IIC T5…T1 Gc) and Class I, Division 2.
• Probe Weight: 323 g per meter (11.4 oz per meter).

Frequently Asked Questions (FAQ)

• Is this probe new and original?
  Yes, we supply a 330104-00-12-10-01-00 that is brand new and 100% original. It comes directly from authorized stock.
• Do you have this model in stock?
  Yes, we keep this Bently Nevada probe in stock. You can order it immediately without waiting for long lead times.
• What is your shipping policy?
  We process and ship orders within 5 days after payment confirmation. Common carriers include FedEx, UPS, and DHL. We offer express shipping for urgent needs.
• Can I return the product?
  Yes. We support a 30-day return policy for unused items in original condition. Contact our support team for return authorization.
• What happens if the probe seal fails below -34°C?
  Exposing the probe to temperatures below -34˚C (-30˚F) may cause premature failure of the pressure seal. Keep the operating temperature within the specified range.
• Does this probe work in wet or humid environments?
  Yes. It passes IEC 68-2-3 humidity testing (93% humidity for 56 days) with less than 3% change in Average Scale Factor.
