Proximity Transducer - Bently Nevada | 330880-28-00-085-03-02

Tersedia (21 unit), siap untuk dikirim
  • Vendor:

    Bently Nevada

  • Tipe:

    Proximity Transducer

  • Country of Origin:

    USA

  • Dimensions:

    14.5*9*9cm

  • Weight:

    1440 g

  • Tag: Proximity transducer

Bently Nevada 330880-28-00-085-03-02 PROXPAC Proximity Transducer

Technical Specifications
Parameter Specification
Model Number 330880-28-00-085-03-02
Operating Temperature -51°C to +177°C
Sensitivity 7.87 V/mm (±5%)
Frequency Response 0-10 kHz
Output Impedance 50 Ω
Measurement Accuracy ±1 mil
Impact Resistance 4J Certified

Construction & Materials
Component Material/Specification
Housing Material PPS Conductive Fiber
Structural Components 304 Stainless Steel
Connector System Gold-plated ClickLoc
Cable Type 75Ω FEP Triaxial
Signal Transmission 305 Meter Maximum
Minimum Target Size 15.2 mm

Certifications & Compliance

  • Class I Division 1 Hazardous Area Compliant
  • BASEEFA IP66 Environmental Rating
  • CSA Impact Certification
  • ATEX Category 3G/3D Approval
  • Industrial Safety Standards Compliance
  • Quality Manufacturing Certification

Electrical Performance

  • Stable 7.87 V/mm Sensitivity Output
  • Consistent ±5% Tolerance Range
  • Reliable 50 Ω Output Impedance
  • Clean Signal Transmission to 305 Meters
  • Accurate 0-10 kHz Frequency Response
  • Minimal ±1 mil Signal Deviation

Environmental Durability

  • Wide Temperature Operation from -51°C to +177°C
  • IP66 Protection Against Dust and Moisture
  • 4J Impact Resistance for Harsh Environments
  • Robust Construction for Industrial Use
  • Long-term Reliability in Demanding Conditions

Application Requirements

  • Minimum 15.2 mm Target Size
  • Industrial Machinery Monitoring
  • Hazardous Area Installations
  • Vibration and Position Measurement
  • Rotating Equipment Protection

Frequently Asked Questions

  • What temperature range can it handle? -51°C to +177°C operation
  • What certifications does it have? Class I Div 1, ATEX, CSA, and BASEEFA IP66
  • What is the measurement sensitivity? 7.87 V/mm linear output with ±5% tolerance
  • What is the minimum target size? 15.2 mm for proper operation

Download Complete Technical Specifications: PROXPAC XL Proximity Transducer Assembly Datasheet
