2711P-K4M5D Allen-Bradley PanelView Plus 400 HMI DC Power

Allen-Bradley 2711P-K4M5D PanelView Plus 400 Grayscale Terminal

Key Technical Specifications

• Brand and Model: Allen-Bradley 2711P-K4M5D belongs to the PanelView Plus 400 series.
• Display Type: Features a grayscale passive matrix FSTN display with a 320 x 240 pixel resolution.
• Display Area: Measures 77 x 58 mm (3.0 x 2.3 in.) for clear process visualization.
• Keypad: Includes 8 function keys (F1 to F8), numeric keys, and navigation keys. Supports 1 million presses with 340 g actuation force. Operators can use the keypad with or without gloves.
• Memory: Provides 5 MB application memory for Series A and 10 MB for Series B or later. Total memory is 64 MB.
• External Storage: Supports CompactFlash cards up to 512 MB for additional file storage.
• Communication Ports: Embeds one RS-232 9-pin D-shell port and USB ports.
• Communication Protocols: Supports DF1 and DH485 protocols for controller connectivity.
• RS-232 Range: Enables point-to-point communication up to 15 meters (49 feet).
• Input Power: Accepts a DC voltage range of 18-30 VDC with nominal 24 VDC. Power consumption is 25 W max (1.0 A at 24 VDC).
• Real-Time Clock: Includes a battery-backed clock with ±2 minutes per month accuracy.

Communication and Connectivity

• The RS-232 port supports DF1 protocol for point-to-point communication with controllers.
• This communication interface allows file transfers and printing capabilities.
• The USB ports enable connection of external peripherals for expanded functionality.
• Function keys support local and global configuration for operational flexibility.
• The 2711P-K4M5D provides reliable connectivity for industrial automation applications.

Installation and Environmental Guidelines

• Turn off all electrical power to the system before installation.
• Install cooling fans to maintain enclosure temperature below 55 °C (131 °F).
• Use a heater when operating below 0 °C (32 °F) to ensure proper functionality.
• Follow the manufacturer installation instructions for safe and secure mounting.
• Use protective and safety equipment during installation.
• Verify all connections are secure and complete before turning on the system.
• The terminal is intended for Pollution Degree 2 industrial environments.

Frequently Asked Questions (FAQ)

• Is this unit new and original?
  Yes, we supply the 2711P-K4M5D as a brand new, original unit from Rockwell Automation.
• Do you have this model in stock?
  Yes, we maintain available inventory for the 2711P-K4M5D.
• What is the shipping time?
  We ship within 5 business days after order confirmation.
• Which carriers do you use for delivery?
  We ship via FedEx, UPS, and DHL for reliable global delivery.
• Can I return this product?
  Yes, we offer 30-day returns for the 2711P-K4M5D in original condition.
• What communication protocol does this terminal support?
  The 2711P-K4M5D supports DF1 and DH485 protocols via the RS-232 port.
• Can I expand the memory?
  Yes, you can install an external CompactFlash card up to 512 MB.
• What is the keypad durability?
  The keypad supports 1 million presses and allows operation with gloves.
• What are the panel cutout dimensions?
  The cutout dimensions are 123 mm (height) x 156 mm (width).
• Does this terminal have a real-time clock?
  Yes, the 2711P-K4M5D includes a battery-backed clock with ±2 minutes per month accuracy.
