Bently Nevada 3300 XL 8 mm Probe – Model 330101-00-70-10-02-00

Key Technical Specifications

• Brand: Bently Nevada (Made in U.S.A).
• Model number: 330101-00-70-10-02-00 – 3300 XL 8 mm probe.
• Unthreaded length option: 00 = 0.0 inches.
• Overall case length option: 70 = 7.0 inches.
• Total length option: 10 = 1.0 meter (3.3 feet).
• Connector type: 02 = Miniature coaxial ClickLoc connector with standard cable.
• Nominal DC resistance (RPROBE): 7.59 ± 0.50 Ω for 1.0m length.
• Extension cable capacitance: 69.9 pF/m (21.3 pF/ft) typical.
• Linear range: 2 mm (80 mils) from 0.25 mm to 2.3 mm (10 to 90 mils).
• Incremental Scale Factor (ISF): 7.87 V/mm (200 mV/mil) ±5% for 0°C to +45°C.
• Deviation from best fit straight line (DSL): Less than ±0.025 mm (±1 mil).
• Probe tip material: Polyphenylene sulfide (PPS).
• Probe case material: AISI 303 or 304 stainless steel (SST).
• Probe temperature range (standard): -52°C to +177°C (-62°F to +350°F).
• Storage temperature: Same as operating range for standard probe.
• Pressure sealing: Viton® O-ring design for differential pressure.
• Relative humidity tolerance: Less than 3% change in ASF after 56 days at 93% humidity (IEC 68-2-3).

Frequently Asked Questions (FAQ)

• Q: Is the 330101-00-70-10-02-00 a brand new original part?
  A: Yes, we supply only brand new and original Bently Nevada probes.
• Q: Do you have this 3300 XL 8 mm probe in stock?
  A: Yes, we keep this model in stock for immediate orders.
• Q: How long does delivery take?
  A: We ship within 5 business days after order confirmation.
• Q: Which shipping carriers do you use?
  A: We ship via FedEx, UPS, or DHL for fast and reliable delivery.
• Q: Can I return the probe?
  A: Yes, we support returns within 30 days of receipt.
• Q: What is the linear range of this probe?
  A: The linear range is 2 mm (80 mils) from 0.25 mm to 2.3 mm distance.
• Q: What temperature can this probe withstand?
  A: The standard probe operates from -52°C to +177°C (-62°F to +350°F).
