کابل برق 10 فوت بنتلی نوادا 3500/94M 119M6509-03

3500/94M 119M6509-03 Power Supply Cable Overview

• Brand & Model: Bently Nevada 3500/94M 119M6509-03 — a power supply cable for Advantech 10" displays.
• Length: 10 feet (3.05 meters) for flexible rack-to-power routing.
• Connects To: Rear of the 3500/94M 190214-02 I/O module and a 24 VDC industrial power supply.
• Required Companion Cable: Assembly 107M3696-01 runs from the module front to the display.
• Power Consumption (Module): Maximum 4.6 watts when operating through this cable.

Technical Specifications

• High-Speed Network Support: Allows monitor status, data, and value transmission between system modules.
• RS232 Port (I/O): Carries touch controller data for interactive display feedback.
• OK LED Indicator: Shows proper operation of the 3500/94M module.
• TX/RX LED Indicator: Indicates active communications between other system modules.
• VGA Port (I/O): Delivers analog red, green, blue, and sync signals to the display.
• Front Port Signals: Provides 24 Vdc power out, VGA signal out, and receives touch commands in.

Environmental Limits & Physical Details

• Operating Temperature: -20°C to 65°C (-22°F to 149°F) for harsh industrial environments.
• Storage Temperature: -40°C to 85°C (-40°F to 185°F) for warehouse or transit storage.
• Humidity: 95% non-condensing, ensuring reliable performance in moist conditions.
• Cable Type: Power supply cable with 24 VDC rating for the 3500/94M I/O module.
• Connector Type: Standard industrial connectors compatible with Bently Nevada racks and Advantech displays.

Frequently Asked Questions (FAQ)

• Is this cable new and original? Yes, we supply a brand new, original 3500/94M 119M6509-03 in factory packing.
• Do you have this cable in stock? Yes, we keep this power supply cable in stock for immediate orders.
• How long does delivery take? We ship within 5 business days after order confirmation.
• Which shipping methods do you use? We use FedEx, UPS, and DHL for worldwide delivery.
• Can I return this cable? Yes, we support returns within 30 days from delivery date.
• What display works with this cable? This cable specifically supports 10" Advantech displays with the 3500/94M module.
• Do I need another cable for full operation? Yes, you also need assembly 107M3696-01 from the module front to the display.
• What power supply voltage does this cable require? It requires an industrial 24 VDC power supply for proper operation.
