IC200ALG260 Analog Input Module General Electric

في المخزون (23 وحدة)، جاهز للشحن
  • Vendor:

    General Electric

  • Type:

    Analog Input Module

  • Country of Origin:

    USA

  • Dimensions:

    17*15*4cm

  • Weight:

    500 g

  • Tags: Analog input module

Emerson IC200ALG260 VersaMax Analog Input Module

Technical Specifications

  • Brand: Emerson (formerly GE Fanuc)
  • Model: IC200ALG260
  • Series: VersaMax
  • Product Type: Analog Input Module
  • Input Channels: 8 single-ended inputs
  • Signal Types: Voltage: -10 to +10 VDC (bipolar), 0 to 10 VDC (unipolar); Current: 4-20 mA
  • Resolution: 12-bit
  • Update Rate: 0.4 ms per channel
  • Filter Response Time: 5 milliseconds
  • Input Impedance: 126 kΩ (Voltage), 200 Ω (Current)
  • Accuracy: ±0.3% typical at 25°C
  • Backplane Power: 130 mA max at 5 VDC
  • Isolation: 250VAC continuous; 1500VAC for 1 minute
  • LED Indicators: INT PWR (Internal Power) and OK status
  • Wiring: Single-ended configuration

Frequently Asked Questions (FAQ)

Is the module brand new and original?

  • Yes, we supply only 100% new and original IC200ALG260 modules

What signals can this input module accept?

  • It accepts both voltage signals (±10V, 0-10V) and 4-20 mA current signals

How many input channels does this module have?

  • The module provides eight (8) single-ended analog input channels

What is the resolution of this analog input module?

  • It features a 12-bit resolution for accurate digital conversion

How soon can you ship the order?

  • We process and ship all orders within 5 business days

What is your return policy?

  • We offer a 30-day return policy for your peace of mind

For pricing and availability, please contact us at sales@nex-auto.com or phone +86 153 9242 9628.
