2711P-K4M5D8 Allen-Bradley PanelView Plus 6 400 HMI

Allen-Bradley 2711P-K4M5D8 PanelView Plus 6 400 Grayscale Terminal

Key Technical Specifications

• Brand and Model: Allen-Bradley 2711P-K4M5D8 belongs to the PanelView Plus 6 400 family.
• Display Type: Features a grayscale TFT LCD with 320 x 240 resolution and 16 gray levels.
• Display Area: Measures 70 x 53 mm (2.8 x 2.3 in.) for clear process visualization.
• Backlight: Uses an LED backlight with a minimum lifespan of 25,000 hours at 25 °C (77 °F). This backlight is not replaceable.
• Keypad: Includes 8 function keys (F1 to F8), numeric keys, and navigation keys. Function keys support local and global parameter assignments.
• Internal Memory: Provides 256 MB RAM and 512 MB nonvolatile memory. Approximately 79 MB free user memory is available for applications.
• External Storage: Supports memory expansion with 1784-SD1 and 1784-SD2 SD cards.
• Communication Ports: Embeds one Ethernet port, one RS-232 port, and two USB host ports.
• Ethernet Capabilities: Supports 10/100 Mbps transmission speed and linear network topology. Users can implement Device Level Ring (DLR) with Advanced Interface Cards (AIC).
• RS-232 Port: Features a 9-pin male connector with a maximum cable length of 15.24 meters (50 feet).
• RS-232 Protocols: Supports DH-485, DF1 full-duplex, and third-party point-to-point communication.
• USB Ports: Allow connection of USB flash drives, mouse, and keyboard for removable storage and external input.
• Input Power: Accepts a DC voltage range of 18-30 VDC with nominal 24 VDC.
• Communication Cable: Uses 2711-NC13 communication cable for RS-232 connections.
• Shipping Weight: Weighs approximately 5 lbs. Shipping dimensions are 14 x 11 x 8 inches.

Communication and Connectivity

• The Ethernet port supports networked connections for application transfers and printing.
• The RS-232 serial port enables uploads and downloads between the terminal and a computer via direct connection.
• This serial port supports DH-485 communication, DF1 full-duplex exchanges, and third-party point-to-point connections.
• The two USB host ports provide flexible peripheral connectivity for data transfer and external input devices.
• Users can connect controllers through both Ethernet and serial interfaces for versatile integration.
• The 2711P-K4M5D8 supports simultaneous communication across multiple ports for comprehensive control.

Installation and Environmental Guidelines

• The terminal is designed for flush mounting to NEMA, UL, or IP-rated enclosures.
• Maintain proper mounting clearances for adequate ventilation and heat dissipation.
• Operate the unit within the specified temperature range to ensure backlight longevity and reliable performance.
• Use the 2711-NC13 communication cable for RS-232 connections when required.
• Ensure the 18-30 VDC power supply meets the nominal 24 VDC requirement for stable operation.

Package Contents

• One Allen-Bradley 2711P-K4M5D8 PanelView Plus 6 400 grayscale operator terminal.
• Mounting clips and installation gasket for panel mounting.
• Product documentation and quick start guide.

Frequently Asked Questions (FAQ)

• Do you have this model in stock?
  Yes, we maintain available inventory for the 2711P-K4M5D8.
• What is the shipping time?
  We ship within 5 business days after order confirmation.
• Which carriers do you use for delivery?
  We ship via FedEx, UPS, and DHL for reliable global delivery.
• Can I return this product?
  Yes, we offer 30-day returns for the 2711P-K4M5D8 in original condition.
• What communication protocols does the RS-232 port support?
  The RS-232 port supports DH-485, DF1 full-duplex, and third-party point-to-point communication.
• Can I expand the memory?
  Yes, you can use 1784-SD1 and 1784-SD2 SD cards for external memory expansion.
• What is the backlight lifespan?
  The LED backlight has a minimum lifespan of 25,000 hours at 25 °C (77 °F).
• What is the display resolution?
  The terminal features a 320 x 240 resolution with 16 gray levels.
• Is this model still active?
  Yes, the 2711P-K4M5D8 has an active lifecycle status from Allen-Bradley.
