Proximitor Seismic Monitor | Bently Nevada 3500/42-06-01

Bently Nevada 3500/42-06-01 Industrial Vibration Analysis Module

Technical Specifications

• Bently Nevada 3500/42-06-01 dimensions: 9.5" × 0.96" × 9.52", weight 2.0lb, suitable for compact installations.
• Frequency range: 1Hz–6kHz with ±1dB flatness for consistent detection across industrial machinery.
• Notch filters: Q=25 @ 60CPM–15.8X RPM for advanced signal refinement.
• Dynamic range: 120dB (0.01–20g RMS) for sensitive vibration measurements.

Core Capabilities

• 24-bit ADC resolution at 51.2kSPS per channel for high-resolution vibration capture.
• 1500V RMS channel-to-ground isolation to prevent electrical interference.
• 512-line FFT analysis with Hanning window for precise spectral data.
• Flexible mounting on DIN rail or 19" rack for seamless industrial integration.

Contact & Support

• For seismic qualification reports or SIL 2 certification, contact sales@nex-auto.com
• Download full datasheet: 3500-22M Transient Data Interface Module Datasheet - 161581
