150-F108NCD Allen-Bradley SMC-Flex Motor Controller - 108A

150-F108NCD Allen-Bradley SMC-Flex Motor Controller Overview

Key Technical Specifications

• Brand: Allen-Bradley
• Model Number: 150-F108NCD
• Category: SMC-Flex Smart Motor Controller (Bulletin Number Solid State Controller)
• Current Rating: 108 Amps with 75 Hp output power at 460V AC.
• Input Voltage: 200-575V AC, 3-phase, with a power circuit tolerance of -15% to +10%.
• Control Voltage: 100-240V AC, featuring a 1600-Volt circuit dielectric withstand.
• Protection Features: Includes electronic motor overload using I2T algorithm, plus stalling, jamming, undervoltage, overvoltage, and phase reversal protection.
• Environmental Tolerance: Operates from -5° to 50° C (23° to 122° F) and withstands 1G peak vibration and 15G operating shock for 11 ms.

Advanced Protection and Communication

• The 150-F108NCD offers high DV/DT protection using an internal RC Network.
• It provides a maximum short-circuit rating of 30KA and a dielectric withstand of 2,200 Volts AC.
• This Allen-Bradley controller uses a built-in DPI communication interface for seamless integration with multiple communication modules.
• LED indicators on the unit clearly show the operational status and diagnostic alerts.
• Two programmable relays (1 NO/NC) provide contacts for up-to-speed and normal operation signaling.

Installation and Mechanical Data

• The unit ships with an open-type enclosure, designed for mounting inside a larger industrial panel.
• It operates without de-rating at altitudes up to 2000 meters above sea level.
• Designed for a non-condensing relative humidity range of 5% to 95%.
• The 150-F108NCD has a net weight of 9.53 kg (21.00 lbs) and compact shipping dimensions.
• Certifications include CE, UL, cUL-us, and CCC for global compliance.

Frequently Asked Questions (FAQ)

• Is the 150-F108NCD a new or refurbished unit?
  We supply the 150-F108NCD as a brand new, original Allen-Bradley unit in factory-sealed packaging.
• How quickly can you ship the 150-F108NCD?
  We maintain this model in stock, so we typically dispatch orders within 5 days via DHL, FedEx, or UPS.
• Does this Allen-Bradley controller support multiple starting modes?
  Yes, the SMC-Flex 150-F108NCD supports 7 different starting and stopping modes, including soft start and kick-start.
• What is the input voltage range for the control circuit?
  The control voltage rating for this Allen-Bradley unit is 100 to 240 Volts AC, making it versatile for various control systems.
