3500/94M-04-00-01 Bently Nevada Class | Div 2 Monitor

Bently Nevada 3500/94M-04-00-01 VGA Display Module Overview

• Brand & Model: Bently Nevada 3500/94M-04-00-01. This VGA display module features a 10-inch screen size. It supports an independent mounting option (Code: 04).
• Hazardous Area Certification: Agency approval option 01 provides CSA/NRTL/C certification. This qualifies the module for Class I, Division 2 locations.
• Power Consumption: 4.6 watts maximum. Input draws power from the system backplane. Front port outputs 24 Vdc for external use.
• Environmental Temperature Range: Operating temperature spans -20°C to 65°C (-22°F to 149°F). Storage temperature extends from -40°C to 85°C (-40°F to 185°F).
• Humidity Tolerance: Handles 95% humidity, non-condensing. This ensures stable performance in humid plant conditions.
• Physical Dimensions (Monitor Module): 241.3 mm x 24.4 mm x 241.8 mm (9.5 in x 0.96 in x 9.52 in). Weight is only 0.73 kg (1.6 lb).
• I/O Module Dimensions: 241.3 mm x 24.4 mm x 99.1 mm (9.50 in x 0.96 in x 3.90 in). Weight is 0.34 kg (0.75 lb).
• Display Compatibility: Works with Advantech 10" (ANA-D3510-100-A1) and Advantech 15" (FPM-8151) displays. The 10" display offers a -20°C to 65°C operating range.
• Communication Ports: Includes an RS232 port for touch controller data. A VGA port outputs analog RGB and sync signals. The front port combines 24 Vdc power, VGA signal, and touch commands.
• LED Status Indicators: OK LED shows proper module operation. TX/RX LED indicates live communication with other system modules.

Frequently Asked Questions (FAQ)

• Is the 3500/94M-04-00-01 a new original module? Yes, we supply only brand new and original Bently Nevada modules. You will receive factory-sealed products.
• What is your stock availability for this VGA display module? We have the 3500/94M-04-00-01 in stock now. Ready for immediate shipment upon order confirmation.
• How fast can you ship this item? We ship within 5 days after order confirmation. Most orders leave our warehouse in 2-3 business days.
• Which carriers do you use for delivery? We use FedEx, UPS, and DHL for global shipments. All provide tracking numbers for your order.
• Can I return the module if it doesn't fit my system? Yes, we support returns within 30 days of delivery. The module must remain unused and in original packaging.
• What display works best with the 3500/94M module? Advantech 10" model ANA-D3510-100-A1 operates from -20°C to 65°C. Advantech 15" model FPM-8151H works from 0°C to 60°C.
• Does this module need special firmware? Yes, you need 3500/94M Firmware 4.06 Rev. C. Also requires 3500/22 TDI with Firmware Rev 1.71 or newer.
• What does agency approval code 01 provide? Code 01 adds CSA/NRTL/C certification for Class I, Division 2 hazardous areas. This differs from code 00 which has no approval.
