1794-IR8 Allen-Bradley Flex I/O RTD-Modul 8 Kanäle

1794-IR8 Allen-Bradley Flex I/O RTD Module

Key Technical Specifications

• Brand: Allen-Bradley
• Model Number: 1794-IR8
• Product Type: Flex I/O RTD Input Module
• Number of Inputs: 8 channels
• Nominal Input Ranges: 1 to 433 ohms
• Resolution: 16 bits across 435 ohms
• Normal Mode Noise Rejection: -60 dB at 60 Hertz
• Channel Bandwidth: 0 to 2.62 Hertz
• Isolation Voltage: 850 Volts DC
• RTD Excitation Current: 718.36 µA
• Flexbus Current: 20mA
• Power Dissipation: 3 Watts at 31.2 Volts DC max
• Thermal Dissipation: 10.2 BTU/hour at 31.2 Volts DC max

FAQ

• Q: Is the 1794-IR8 a brand new original module?
  A: Yes, we supply only a brand new and original 1794-IR8 from Allen-Bradley.
• Q: How many input channels does this RTD module provide?
  A: The 1794-IR8 gives you eight dedicated RTD input channels.
• Q: What is the resolution of the 1794-IR8?
  A: This module delivers 16-bit resolution across 435 ohms for precise measurements.
• Q: Do you have this item in stock?
  A: Yes, we keep the 1794-IR8 in stock for immediate orders.
• Q: What is your shipping time?
  A: We will ship your 1794-IR8 within 5 business days after payment.
• Q: Which carriers do you use for delivery?
  A: We ship via FedEx, UPS, or DHL depending on your location.
• Q: Can I return the module if it does not meet my needs?
  A: Yes, we support a 30-day return policy for the 1794-IR8.
• Q: What terminal bases work with the 1794-IR8?
  A: You need the 1794-TB2, 1794-TB3, or 1794-TB3T terminal base.
• Q: What is the normal mode noise rejection value?
  A: The 1794-IR8 provides -60 dB noise rejection at 60 Hertz.
• Q: What sensors does this module support?
  A: It supports platinum, nickel, and copper RTD sensors with various alpha values.
